Weslie - Sort of Leslie Simulator

Posted by fx-fidden on
URL: http://guitar-fx-layouts.238.s1.nabble.com/Weslie-Sort-of-Leslie-Simulator-tp50928.html

Hello, I found this project by General Guitar Gadget:
https://generalguitargadgets.com/effects-projects/modulationecho/weslie-modulator/

It's a kind of Leslie simulator, it's more a warble effect, but it's pretty unique and new to build.

Here's a demo:
https://www.youtube.com/watch?v=6R4fKmiO_jk

It seems to have a volume drop, maybe a booster after the circuit could be useful.

I tried to draw a veroboard layout (no boost).

That's it, UNVERIFIED.



Tell me if I made some mistake.
